Supply the turnkey project&design for customer
 |
| Place of Origin: | China |
| Brand Name: | Fill Drink |
| Certification: | CE ISO |
| Model Number: | JG-200 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 8500USD |
| Packaging Details: | wood packing |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets per month |
| Machine Material: | SUS 304 | Warranty: | 1 Years |
|---|---|---|---|
| After-sales Service Provided: | Online Support,Video Technical Support,commissioning And Training,Field Maintenance And Repair Service | Dimension: | 440*345*300mm |
| Name: | Solid Ink Roll Coding Machine | Color: | As Requested |
| Power: | 180kw | Applicatioin: | Beverage/Beer/Juice/Cola/PET Water Bottles |
| Packing Material:: | PE Film | ||
| High Light: | 200DPI Bottle Printing Machine,200DPI laser date coding equipment,laser date printing machine Plastic Bottles |
||
200DPI Precision Automatic Laser Date Coding Equipment For Plastic Bottles
Product Description:
Designed for low duty applications, the Printer 1210 continuous inkjet printer is the perfect variable data printing machine to fulfill applications that involve printing codes 8 to 10 hours per day / 5 days a week.
The printer is engineered to keep your line up and running longer.
The Printer 1210 is designed for customers with simple coding needs like date printing and is ideal for the food, beverage, chemical, pharmaceutical and personal care/cosmetics industries.
Engineered to keep your line running:
Our advanced core technology includes all ink system filters and common wear parts
Intervals of up to 6,000 hours between preventative maintenance
Auto cleaning print head for fast start-ups, even after extended shutdowns
Optional internal air pump eliminates need for external air, minimizing potential for contaminants to enter the ink stream
The details of product:
Technical parameters:
| Laser type | Metal tube carbon dioxide laser |
| Laser power | 30W |
| Laser head | Length: 750mm Width: 160mm Height: 180mm |
| Whole machine Power | 800W |
| Print line speed | ≤150m/min |
| Number of flight mark lines | 10X 10 |
| Minimum line width | 0.15mm |
| Minimum character | 0.40mm |
| Repeating accuracy | ±0.01mm |
| Laser wave length | 10.6µm |
| Divergence angle miliradian | 7.5mrad |
| Fastest printing line speed | 7000mm/s |
| Number of characters printed per second | 1200bps |
| Focal length | 120mm |
| Rows | Any rows |
| Character height | 0.5~100mm |
| Print information | Line height 0.5-100mm,Max 300mm |
| Print range | 90*300mm |
| Cooling way | Air cooling |
| Environment literature | 5-45℃ |
| Environment humidity | 90% non-condensing |
| Print content | English letter,Arabic numerals and patterns |
| Optimal print interval | ≥1mm |
| Power Supply | Ac 110V-220V/50HZ,5A |
| Humidity | 10%-90% |
| Communication interface | USB,RS232/485,Ethernet |
| Protection degree | IP54 |
| Detection settings | Photoelectric sensor,PNP/12V |
| Size and weight: |
Laser head 850*170*195mm 25KG Laser bracket 1500*600*580mm 22KG Controller 275*210*30mm 2KG |
1. we can send you the video of the running machine.
2. you are always welcome to come to visit our factory, and you may see the operation of the machines here . We will make the arrangement to pick you up when you come .
3. If we get the permission of the customer who has brought the machines from us ,we can tell you their contact information, you can go to visit their factory.
Customized service
1. we can design the machines according your requirements(material ,power,filling type,the kinds of the bottles, and so on).
2. at the same time we will give you our professional suggestion .
After-sales service
1. we will provide the bill of load on time to make sure you can get the machine quickly
2. when you finish the Preparation conditions ,our engineer will go to your factory for the installation, testing and also training .
3. we provide one year warranty with spare parts free.
